Ways of Seeing with Computers workshop (Rulr workshop), NODE 15

Author: elliotwoods
Date: 06 May, 2015
Category: misc
Credits:

elliotwoods, sebl

Download

64bit

0-Rulr Workshop-ALL WORKING.zip
06 May, 2015 - 12:51

Description

All the goods for:

  • Calibrating cameras
  • Calibrating kinect<>projector
  • Calibrating camera<>projector
  • Taking graycode scans in 2D and 3D (triangulated graycode scan)
  • Loading kinect<>projector calibrations into VVVV for live 3D projection mapping
  • Loading triangulated point clouds into VVVV for pixel-for-pixel 3D projection mapping onto scanned surfaces

Thanks to Simon Hänggi for getting all the files together at the end of the workshop and making this ZIP.

Prerequisites:

  • Visual C++ 2013 x64 Runtime
  • Kinect Runtime v2.0 v1409 (aka Kinect SDK)
  • BlackMagic drivers (either Camera drivers or DeckLink drivers)

All prerequisites can be downloaded from: https://drive.google.com/open?id=0B_S1z3_AWMRSfmhrRDd1ZVYtY3lPUW5TR29XbDZ2Q1pVYWFrSXZMTVRkZmxsSF82ajlBTDg&authuser=0.

Future versions shouldn't need Kinect or BlackMagic drivers, but the one packaged here does.

Comments

Comments are no longer accepted.
Please create a new topic in the vvvv beta forum to discuss this contribution.
guest
06 May, 2015 - 09:31

Anything missing?

elliotwoods
06 May, 2015 - 15:34

not any more :)

guest
08 May, 2015 - 13:20

App_Rulr.exe fails to run. (Using Windows 8.1 Pro) It throws up this error:

Unhandled exception at 0x00007FFEE7364A30 (msvcr120.dll) in App_Rulr.exe: Fatal program exit requested.

Problem signature: Problem Event Name: BEX64 Application Name: App_Rulr.exe Application Version: 0.0.0.0 Application Timestamp: 553fa7bc Fault Module Name: MSVCR120.dll Fault Module Version: 12.0.21005.1 Fault Module Timestamp: 524f83ff Exception Offset: 0000000000074a30 Exception Code: c0000409 Exception Data: 0000000000000007 OS Version: 6.3.9600.2.0.0.256.48 Locale ID: 2057 Additional Information 1: 943d Additional Information 2: 943dfc6d2256c58d0a0b9cd340ae84a7 Additional Information 3: fb90 Additional Information 4: fb903bd767605edae5e08c522ecb7f01

guest
08 May, 2015 - 16:14

run as admin?

guest
08 May, 2015 - 21:19

Hi guest, I re-tried but it still produces the error above.

princemio
09 May, 2015 - 10:46

that shit is just tooooo cooooool !!!

microdee
09 May, 2015 - 17:50

i have the same as guest #1

eps
09 May, 2015 - 21:27

you may need to install Blackmagic Camera utilities to make Rulr work. at workshop there was v.2.0.1; one may get any of more recent instead :: https://www.blackmagicdesign.com/support/family/professional-cameras

// just checked that without these Rulr throws exactly same error

guest
10 May, 2015 - 09:31

Yeah that's done it, thanks Eps... ditto Princemio!

elliotwoods
12 May, 2015 - 02:42

Thanks eps for posting that! I was about to come in with that.

let me add a comment above

sinus
12 May, 2015 - 06:24

thank you for this contrib!!

mrboni
01 Jun, 2015 - 14:09

Did anyone record the workshop?

drehwurm
08 Jul, 2015 - 13:08

Is there any dokumentation on how this is being used?

Greetings,

Alex
